Welded Gabion Box
Welded Gabion Box
Features & Benefits
Welded Gabion Box are wire mesh containers welded with high quality steel wire, then connected by spirals, assembled with spacers/stiffeners. They can be filled on site with hard durable stone materials to form mass gravity retaining structures. Owing to their inflexibility, welded gabion box can adapt to differential settlement or be used in water courses.
Gabion Weaving: Straight twist, reverse twist, double twist and welded
Feature: Economic,Simple installation, corrosion resistant, no collapse, good permeation ,less transport freight.
Surface treatment: hot-dipped galvanized, galvanized aluminum alloy or PVC coated, etc.
Application：
1.Controlling and leading the river and flood.
2. Flood discharge and lead flow.
3. Rock fall defending.
4. Preventing the water and soil lost.
5. Protecting the bridge.
6. Reinforce fabric.
7. Seashore recovery project.
|
Length (mm) |
Width (mm) |
Height (mm) |
Diameter (mm) |
Mesh Spacing (mm) |
Spirals (mm) |
|
2000 |
1000 |
1000 |
3-6 |
50*50 75*75 50*100 100*100 |
300 500 600 1000 2000 |
|
2000 |
1000 |
500 |
|||
|
2000 |
500 |
500 |
|||
|
2000 |
300 |
300 |
|||
|
1000 |
1000 |
1000 |
|||
|
1000 |
1000 |
500 |
|||
|
1000 |
500 |
500 |
|||
|
500 |
5000 |
500 |
|||
|
1200 |
600 |
600 |
|
Common Specification of Welded Gabion Box |
|||
|
Wire diameter:2.0-5.0mm |
|||
|
Nominal Box sizes(m) |
Mesh size(mm) |
No. of diaphragms(no.) |
Capacity per box(m3) |
|
1.0x1.0x0.5 |
50x50 75x75 50x100 100x100 |
0 |
0.50 |
|
1.0x1.0x1.0 |
0 |
1.00 |
|
|
1.5x1.0x0.5 |
0 |
0.75 |
|
|
1.5x1.0x1.0 |
0 |
1.50 |
|
|
2.0x1.0x0.5 |
1 |
1.00 |
|
|
2.0x1.0x1.0 |
1 |
2.00 |
|
|
3.0x1.0x0.5 |
2 |
1.50 |
|
|
3.0x1.0x1.0 |
2 |
3.00 |
|
|
4.0x1.0x0.5 |
3 |
2.00 |
|
|
4.0x1.0x1.0 |
3 |
4.00 |
|
|
Remark:customized size is also available |
|||
